Cyber Lift

Creative pallet transportation solution, compare with AMR carries pallet with frame support idea, GALAXIS VFR (Vary-narrow-aisle Forklift Robot) Cyber Lift can pick up the pallet from the ground directly. And with light structure mast makes VFR be with up to 2,000mm lifting height, that brings various applications. Pallet can be transported between multiple devices with different docking height, storage pallet in low level racking as well.


The VFR series features a pioneering side-facing fork pickup mechanism that enables precise alignment and lifting of pallets in a single, fluid maneuver, even within confined aisles. Our VFRs are fully compatible with mainstream logistics information systems, including ERP, WCS, and WMS, allowing for fast, accurate, and flexible handling and pallet-to-person workflows. They also deliver superior load-bearing capacity and operational stability across the core intralogistics functions of storage, sorting and transport.

Watch the Video
This video can’t be reached
www.youtube.com took too long to respond.
Try:

Checking the connection

Checking the proxy and the firewall

Running system network diagnostics

MODEL
CL1QS(1m)
Max. Payload
Max. Payload
1,000 kg
Rated Speed
1.2 m/s
Rated Speed
Lifting Height
MAX 1,000mm
Lifting Height
Endurance
Endurance
12H
Navigation
Navigation
Hybrid SLAM /QR code
Min.aisle width: 1,650mm
Gradeability: 1.5°
Position time: 1.5s
Docking equipment: Workstations/conveyors/racks etc.
Applicable pallet sizes (mm): 1100*1000~1200*1200
CL1QS(2m)
Max. Payload
Max. Payload
1,000 kg
Rated Speed
1.2m/s
Rated Speed
Lifting Height
MAX 2,000mm
Lifting Height
Endurance
Endurance
12H
Navigation
Navigation
Hybrid SLAM/QR code
Min.aisle width: 1,650mm
Gradeability: 1.5°
Position time: 1.5s
Docking equipment: Work stations/conveyors/racks etc.
Applicable pallet sizes (mm): 1100*1000~1200*1200
CL2QS
Max. Payload
Max. Payload
1000kg
Rated Speed
1.2m/s
Rated Speed
Lifting Height
Max.2,200mm
Lifting Height
Endurance
Endurance
12H
Navigation
Navigation
Hybrid SLAM/QR code
Min.aisle width: 1,650mm
Gradeability: 1.5°
Position time: 1.5s
Docking equipment: Work stations/conveyors/racks etc.
Applicable pallet sizes (mm): 1100*800~1200*1200
CC5
Max. Payload
Max. Payload
5,500kg
Rated Speed
1.2m/s
Rated Speed
Lifting Height
Max.5,500mm
Lifting Height
Endurance
Endurance
8H
Navigation
Navigation
Hybrid SLAM/QR code
Min.aisle width: 1,800mm
Gradeability: 1.5°
Position time: 1.5s
Ambient temperature: 0~40℃
Applicable pallet sizes (mm): 1100*800~1200*1200
Product Features
Compactness
Compactness

Very narrow aisle required, up to 1,650mm

Compact body, capable to spin around in the aisle

Intelligence
Intelligence

Adopts LIDAR to scan the pallet with correction algorithm

Intelligently inspects the pallet position


Safety
Safety

5m wide range obstacles detection function

With CE level architecture and ISO3691-4 international standard

Flexibility
Flexibility

Directly transfers and lifts the pallet from ground without pallet frame

Easy deployment, performance on demand by changing the number Bots

Efficiency
Efficiency

1.5 seconds positioning time, more efficient than traditional forklifts

Endurance
Endurance

Up to 12 hours' active operation time

Battery can be manually replaced as well
